Tech Specs
Gallery
Overview

GPD Pocket 3

Order Now
Français

8 Inches / 1920×1200 Screen Resolution
Intel Core i7-1195G7 / Intel Pentium Silver N6000
16GB LPDDR4x 3733 / 8GB LPDDR4x 2933
1TB / 512GB PCIe M.2 NVMe SSD

i7-1195G7 / N6000
Intel Gen11 Core / Pentium
16GB / 8GB LPDDR 4x
3733MHz / 2933MHz
PCIe M.2 NVMe SSD
1TB / 512GB
8 Inches, IPS
1920×1200

Thunderbolt 4
Supports USB4
Wi-Fi 6E
3600Mbps
RJ45
2500Mbps

RS-232 Module
9-pin Serial Devices
KVM module
System and Network Management
4096-level Pressure Sensitivity
Original Handwriting
180 Degree Movement
Backward Foldable Screen
IR Camera
2 Million Pixels
UNIBODY Chassis
6061 Aluminum Alloy
1-second Fast Unlocking
Privacy Protection
Only 0.7kg
Handheld PC
2.5mm Screw Holes
Stand or Hanging

Pocket 3 is the perfect combination of professional O&M functions and portability. It integrates a complete set of O&M interfaces within a 8-inch compact body that weighs only 0.7kg, allowing the engineer to carry less but still comfortably dealing with front-line tasks such as debugging, remote operation, maintenance, and real-time monitoring.

Only 0.7kg

Professional O&M Functions

Portability

8-inch H-IPS screen featuring outdoor visibility, exclusive ICC color calibration (making the screen suitable for professional use cases) , 180-degree opening, 1920×1200 resolution, 284ppi pixel density, 16:10 ultra-wide viewing angle, 500nit brightness, DC dimming and billions of brilliant colors. It is a bright and vivid display for your viewing pleasure.

8-inchs IPS

10-point Touch Control

500nit

16:10

1920 × 1200

248ppi

DC Dimming

Temperature Control Device

PLC Controller

Cashier

ISDN Terminal Adapter

Tax Control Machine

Industrial Robot

PLAM

CNC Machine Tool

Handwriting Board

Touchpad

Touch Screen

Access Control System

IPC

LED Display

External Modem

Barcode Printer

PDA

Industrial Instrument

Set-Top Box

Scanner

The modular I/O port design allows a tiny PC like Pocket 3 to adapt well in different use cases (by swapping between different expansion modules). The serial port expansion module of Pocket 3 uses the standard EIA RS-232 communication protocol and can connect to various 9-pin serial devices.

Support More Serial Device:

The single KVM  port control module for Pocket 3 can be used to access and control another computer for system and network device management. It integrates HDMI IN and USB IN ports, so you only need an HDMI cable or HDMI to VGA cable to connect Pocket 3 to the targeted server and fully control the server through the Pocket 3's own keyboard and mouse.


Unlike "remote desktop", the KVM control module is used for hardware-level access control covering the entire use process of the targeted server, from booting, BIOS settings to operations within the OS. It is hot-swappable but has no IP KVM, so it does not support remote management and is suitable for managing local network equipment that has no keyboard, mouse and display.

HDMI IN

USB IN

Keyboard & Mouse control

Note:
KVM compatible OS: Windows, Linux, Unix, macOS
KVM compatible hardware: General server, dedicated server, soft router, NAS
KVM compatible applications: Information control center, call center, securities/financial trading system, industrial control, teaching, bank data center, test center

Our specifically designed swivel screen made with powder metallurgy technology allows for an effort-less 180 degree movement (which can be done with one hand) in a clockwise rotation around the Y axis. It has passed the durability test (100,000 continuous robot arm operations including rotation, opening and closing) with a serviceability rate of 99.3%.

180° Flip

180° Fotation

One-handed Rotation

3D View

4096-level Pressure

Pocket 3 supports active stylus with 4096-level pressure, original handwriting, and is compatible with Surface Pen (using Microsoft MPP 2.0 protocol), allowing to write notes, annotations and signatures whenever you want. It allows you to make creative content with sufficient precision.

Original Handwriting

Pocket 3 has a light and strong all-aluminum (6061) body manufactured according to the same unibody design used by Apple devices, which has 36 level  of processing treatment, including ultra-fine CNC machining that eliminates chamfer burrs, sand polishing for achieving a glass-like smooth surface with delicate texture, distributing liquid dyes evenly into tiny cavities through capillary effect, anodizing process for forming a super protective layer, and  polishing with magnetized iron powder for creating a jade-like smooth appearance!

All-aluminum Body

Unibody Design

CNC Machining

36 Level

QWERTY

Our widely acclaimed chiclet chocolate style "QWERTY" keyboard, which has won the German Red Dot Award, is optimized for typing with both hands by concentrating the most important keys on the center, making it very comfortable to play keyboard and mouse-controlled games on this device!

Chiclet Keyboard

Backlight

Off With Key

You don't have to carry a mouse around with Pocket 3! Keeping the ergonomic design of Micro-PC, with three mouse buttons on the left and touchpad on the right, Pocket 3 is optimized for thumb control while holding the device with both hands, allowing operations efficiency exceeding traditional clam-shell form factor conveniency.

Three Mouse Buttons

TouchPad

Pocket 3 has two different hardware versions (high-end and base).  The high-end version comes with the latest 11th gen i7-1195G7 processor, which has 4 cores and 8 threads, a core frequency of up to 5.0GHz, and 4 cores maximum frequency of 4.6GHz. Its overall performance are surpassing the 8700K, a desktop processor, which is making it suitable for enjoying AAA games and for working with various large-scale design software. The base version is equipped with Intel Pentium Silver N6000 processor, which has 4 cores 4 threads, the new Tremont micro-architecture, 10W TDP, single and multi-core performance surpassing that of Intel Core m3-8100Y, making it suitable for running mainstream office software and enjoying 4K Blu-ray movies for a longer period of time.

4 Cores / 8 Threads

4 Cores / 4 Threads

12MB Level 3

4MB Level 3

5.0 GHz Turbo (1 Core)

3.3 GHz Turbo (1 Core)

4.6 GHz Turbo (All Core)

2.5 GHz Turbo (All Core)

16GB dual-channel LPDDR4x high-speed memory with 86GB/s bandwidth, which coupled with Intel 11th-generation 1195G7 processor can support opening multiple applications at the same time without stuttering, and reducing rendering time of large editing tools such as PR and AE by 40% (compared with models using 1130G7, a same-generation ultra-low-power processor).

16GB Dual-channel

8GB Dual-channel

86GB Memory Bandwidth

86GB Memory Bandwidth

3733MHz Memory Frequency

2933MHz Memory Frequency

1195G7

N6000

Note:

The default memory frequency of Pocket 3 high edition is 3733MHz, which is actually LPDDR4x 4266, it can be manually changed to 4266MHz t in BIOS. The low edition is also equipped with LPDDR4x 4266, but the N6000 processor supports max to LPDDR4x 2933, so the actual frequency is 2933MHz.

Note:

Test software: AS SSD Benchmark;
Test environment: 1195G7, LPDDR4x 4266, Samsung 980 PRO 500GB;
Different versions of AS SSD Benchmark test results are slightly different, and the heat dissipation will severely affect the read/write speed;
The chart shows read and write speed on PCIe 4 SSD. The standard configuration for the shipped machine is PCIe 3 SSD. If you want to ensure to reach the speed of the SSD in the chart, please purchase PCIe 4 SSD and swap it by yourself.

Breaking through design limitations, Pocket 3 supports single and double-sided solid-state drives and the latest PCIe 4 protocol, which has a top speed (up to 7.877GB/s) 2 times that of PCIe 3. With Pocket 3, you can say goodbye to stuttering and low-speed reading and writing and have significantly improved work efficiency.

5038MB/s Sequential Reading

3346MB/s Sequential Writing

1TB / 512GB

Located at the upper left corner of the screen is a 1080P high-definition ultra-thin mini camera that has 2 million pixels and features a larger/wider 77° field of view, so that you can communicate with your family anytime, anywhere via live webcast or hold video conferences with colleagues.

IR Lens

2-million-pixel Camera

1600×1200

77° Field of View

Pocket 3 takes the lead in supporting Window 11(Default built-in Windows 10 Home)which will bring you an extraordinary new experience with new logo, start menu, software library, system theme and rounded rectangular frosted glass effect.You can even use native Android apps on it, and experience on it with games such as "League of Legends"!

TPM 2.0

Support Windows 11

Support Android Apps

Pocket 3 comes with top of line AAC linear stereo speakers from Germany. With a sound cavity design using Bass materials (the equivalent to a 0.9cc sound cavity) and a double coil drive that enables diaphragm load balance and double amplitude enhancement, Pocket 3 can provide a great volume with clear sound!

Linear Stereo Speakers

Bass Material

Diaphragm Load Balance

Double Amplitude Enhancement

Pocket 3 come with three USB3.2 Gen2 ports, all with a 10Gbps transfer rate (1000MB/s). This means that it can transmit data at a higher speed and connect with more USB devices at the same time, including external hard drives, printers, scanners, keyboards, mice, speakers, gamepads, hubs, etc., without the need for repeated plug-in/out operations or even an external usb hub.

U-disk

SSD

HDD

Keyboard

Mouse

Joystick

Printer

Smart Phone

Pocket 3 has a great port selection that supports a wide range of applications, such as watching a movie while browsing stock trends or playing games by connecting two external monitors.

Two External Monitors

4K / 60Hz

Note:
The base version of Pocket 3 has 1 HDMI 2.0b port and 1 full-featured Type C port, both supporting up to 4K/60Hz displays;
The high-end version of Pocket 3 has 1 HDMI 2.0b port, and 1 Thunderbolt 4 port which supports up to 8K/60Hz displays.

Built-in 10000mAh (38.5Wh) high-capacity battery that allows an average of 8.5h of local video playback (test result). High-capacity battery; in combination of 45W PD fast charge and high-efficiency direct power supply to the motherboard; allows you to concentrate on working without  hving concerns about battery life.

10000mAh

Li-lion Battery

45W PD

Fast Charge

8.5 Hours
Video Playback

Pocket 3 supports PD fast charging protocol with 45W mobile power bank. When you are away from home, it can share the same mobile power banks with your mobile phone,  allowing it to be recharged anytime and anywhere, effectively solving any anxiety of remaining battery.

15V / 3A

Output

45W

PD Power Bank

Shared Charging

With Mobile Phone

It can be used with a phone lanyards to prevent accidental loss and drop, making it easier and safer to carry and use the device on the go.

GPD Pocket 3





Screen Size: 8 Inches, 10-point Touch Control

CPU: Intel Core i7-1195G7 / Intel Pentium Silver N6000

GPU: lntel Iris Xe Graphics 96eu / Intel UHD 630 Graphics 32eu

DDR: 16GB LPDDR4x 3733 / 8GB LPDDR4x 2933

SSD: 1TB / 512GB M.2 NVMe

Stylus: Active Pen With 4096-level Pressure Sensitivity, Original Handwriting

RS-232: Expansion module × 1

KVM: Expansion module × 1

Thunderbolt 4: × 1

USB A: ×3

HDMI: ×1, 2.0b

RJ45: ×1

Thermal Design: Active cooling with large fans

WLAN: Wi-Fi 6E / Wi-Fi 6

Battery Capacity: 38.5Wh, 10000mAh

Length: 198×137×20 mm

Net Weight: 0.7kg
